specs

Power

Engine

Liquid-cooled, 4-stroke In-Line Four

Displacement

1,043 cc

Bore x Stroke

77.0 x 56.0 mm

Compression Ratio

11.8:1

Fuel System

Fuel injection: Ø38 mm x 4 (Keihin) with oval sub-throttles

Ignition

Digital

Transmission

6-speed, return

Final Drive

Sealed chain

Starting System

Electric

Performance

Front Suspension / Wheel Travel

41 mm inverted fork with top-out springs, stepless compression and rebound damping and spring preload adjustability

Rear Suspension / Wheel Travel

Horizontal Back-link, gas-charged shock, with stepless rebound damping and spring preload adjustability

Front Tire

120/70ZR17M/C (58W)

Rear Tire

190/50ZR17M/C (73W)

Front Brakes

Dual semi-floating 310 mm petal discs. Caliper: Dual radial-mount, monobloc, opposed 4-piston

Rear Brakes

Single 250 mm petal disc. Caliper: Single-piston

Lubrication

Forced lubrication, wet sump

Turning Radius

29° / 29°

Details

Frame Type

Twin-tube, aluminium

Rake/Trail

101 mm

Overall Length

2,045 mm

Overall Width

790 mm

Overall Height

1,055 mm

Ground Clearance

125 mm

Seat Height

815 mm

Curb Weight

221 kg

Fuel Capacity

17 litres

Wheelbase

1,435 mm

**Curb weight includes all necessary materials and fluids to operate correctly, full tank of fuel (more than 90 percent capacity) and tool kit (if supplied). When equipped, California evaporative emissions equipment adds approximately 2.2 lb.

KAWASAKI CARES: Read Owner's Manual and all on-product warnings. Always wear a helmet, eye protection and proper apparel. Never ride under the influence of drugs or alcohol. Adhere to the maintenance schedule in your Owner’s Manual. ©2019 Kawasaki Motors Corp., U.S.A.

Specifications subject to change.
